BC10 4 Slot Battery Charger

Specifications

• Technical

  ---

  Part Number(s)

  E461816

  Enclosure Color

  Black

  Compatibility

  Compatible with Elo M50 Batteries

  I/O Ports

  12V DC IN Jack Connector

  Dimensions

  2.71" x 7.21" x 6.53" / 69 mm x 183.8 mm x 166 mm

  Shipping Box Dimensions

  9.25" x 6.93" x 8.27" / 235 mmx 176 mm x 210 mm

  Mounting Options

  Countertop or Wall (with included wall mount bracket)

  Weight (Unpackaged)

  1.7 lbs / 0.75 kg

  Weight (Packaged)

  4.4 lbs / 2.0 kg

  Operating Temperature

  0°C to 40°C / 32°F to 104°F

  Storage Temperature

  -20°C to 50°C / -4°F to 122°F

  Humidity

  Operating: 20% - 80%
  Storage: 10% - 95%

  Regulatory approvals and declarations

  UL, FCC (US) - Class B
  cUL, IC (Canada)
  CB (International safety)
  CE (Europe) - Class B
  VCCI (Japan)
  RCM (Australia)
  China RoHS

  MTBF

  50,000 hours demonstrated

  Warranty

  1-year

  What's in the Box

  Power Adapter 12V/7.5A - 90W
  US power cord
  EU power cord
  Wall mount bracket option
  2x M4 screws to attach battery charger to wall mount bracket
  1x Tie wrap for cable management
  QIG
