Elo Edge Connect™ Magnetic Stripe Reader (MSR)

Specifications

• Technical

  ---

  Part Number

  E001002

  Enclosure Color

  Black

  Swipe Speed

  4~60 ips (10.1~152.4 cm/sec)

  Swipe Direction

  Bi-directional

  Card Width

  0.025 ~0.035 inches

  Number of Tracks

  2 Track non-encrypted
  Support for 3 tracks

  Power Supply

  5V USB

  Power Consumption (Typical)

  0.5W

  Interface

  Micro USB

  Supported Emulation Modes

  HID and Keyboard

  Supported Formats

  ISO 7811
  ISO 7810
  AAMVA
  CA DMV
  ANSI

  Supported Operating Systems

  Ubuntu Linux LTS
  Windows POSReady 7 32-bit
  Windows Embedded Pro 7 32-bit
  Windows Embedded Pro 7 64-bit
  Windows Industry Embedded Pro 8.1 32-bit
  Windows Industry Embedded Pro 8.1 64-bit
  Android 4.4.2

  Mounting Options

  Ability to mount directly to select Elo computers and monitors

  Weight (Unpackaged)

  0.15 lbs / 0.07 kg

  Weight (Packaged)

  0.4 lbs / 0.18 kg

  Warranty

  2-year

  What's in the Box

  MSR
  Quick Install Guide
  2 screws for mounting
